HPM713 Anti-corrosive Flush Diaphragm Pressure Transmitter

Accuracy:±0.5%FS (std.)
Measuring range: -1…0~0.2…400bar
Working temperature: -40~85℃
whatsapp sharing button
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

The HPM713 ceramic diaphragm pressure transmitter utilizes an advanced ceramic piezoresistive core as its sensitive element and features a threaded installation with a flat diaphragm design. Ceramics exhibit exceptional properties including high elasticity, wear resistance, corrosion resistance, and rapid heat dissipation. These characteristics contribute to the transmitter's outstanding thermal stability, enabling reliable operation in temperatures ranging from -40 to 120 degrees Celsius with minimal temperature drift.

Due to the absence of filling liquid in the ceramic sensor, it eliminates the risk of process pollution. The dry ceramic diaphragm remains unaffected by the installation direction. The exposed diaphragm on the product's end face directly senses the pressure, effectively eliminating issues such as scaling, unsanitary conditions, and viscous pressure blockage. As a result, this transmitter finds wide application in measuring media containing particle impurities, as well as in pressure measurement scenarios susceptible to blockage or scaling.

Additionally, the HPM713 transmitter proves valuable in hygienic industries such as food, medicine, and winemaking. Its reliable performance and resistance to process contamination make it an ideal choice in these sectors.

Overall, the HPM713 ceramic diaphragm pressure transmitter offers superior functionality and versatility, making it suitable for a wide range of demanding applications.


  • Measurement of gauge and absolute pressure of gases or liquids in the field of
  • Industrial process control.
  • Water treatment industry.
  • Environmental protection industry.
  • Food industry; Pharmaceutical industry


  • Stainless steel shell for durability and corrosion resistance.

  • Anti-corrosion ceramic sensor (96% Al2O3).

  • Threaded flat membrane interface, easy to clean and prevent clogging.

  • Wear-resistant and resistant to negative pressure.

  • Wide temperature range: -40℃ to 120℃, low temperature drift.

  • Supports negative pressure, absolute pressure, or composite pressure measurement.

  • Multiple output signals and electrical interfaces supported.

  • Waterproof and breathable design for added protection.

Technical Parameters

Pressure Range

Rated Pressure


Minimum Pressure



1.5x of full scale

Measuring Medium


Various liquids and gases compatible with contact materials

Output/Power Supply


Two wire:4-20mA   /  Vs=10-30V


Three wire: 0-5V    /  Vs=8.5-30V


Three wire:0~10V    /  Vs=12-30V


Four wire:Modbus-RTU/RS485 / Vs =3~8 VDC or 10~30 VDC




Long term stability


(includes linearity, hysteresis, and repeatability)*

Temperature Drift Characteristics

Zero temperature drift

≤±0.4%FS/10℃(25~85℃,reference 25℃)

Fullness temperature drift

≤±0.15%FS/10℃(-10~85℃,reference 25℃)
