The HPM410-F flange cage liquid level transmitter is a fully sealed submersible device that utilizes a high-quality and highly stable pressure sensor as the sensing element. This product is designed with an oversized flat diaphragm pressure sensing structure and a robust flange cage protection structure, making it suitable for measuring liquid levels in environments with silt, mud, and sedimentation. Moreover, it effectively guards against solid floating objects and suspended solids, preventing clogging.
The outer casing of this product undergoes a fully welded process, ensuring reliable sealing at each connection point through multiple design features. The internal potting process guarantees a long operational lifespan. The upper section of the product is equipped with NPT threads, providing flexibility for secure attachment to pipes or conduits. Additionally, the entire device can be easily transported using the lifting ring.
The HPM410-F flange cage liquid level transmitter is a fully sealed submersible device that utilizes a high-quality and highly stable pressure sensor as the sensing element. This product is designed with an oversized flat diaphragm pressure sensing structure and a robust flange cage protection structure, making it suitable for measuring liquid levels in environments with silt, mud, and sedimentation. Moreover, it effectively guards against solid floating objects and suspended solids, preventing clogging.
The outer casing of this product undergoes a fully welded process, ensuring reliable sealing at each connection point through multiple design features. The internal potting process guarantees a long operational lifespan. The upper section of the product is equipped with NPT threads, providing flexibility for secure attachment to pipes or conduits. Additionally, the entire device can be easily transported using the lifting ring.
Application
Liquid level measurement in sludge pits and mud tanks
Sewage water level in lifting station
Clarifier, digester
Alum jar, lime slurry
Wet wells, storm drains
Application
Liquid level measurement in sludge pits and mud tanks
Sewage water level in lifting station
Clarifier, digester
Alum jar, lime slurry
Wet wells, storm drains
Features
1. Aluminum alloy electronic shell with IP65 protection grade.
2. On-site display with simultaneous output of 4 ~ 20mADC and other remote signals.
3. Reverse polarity protection and instant over-current and over-voltage protection measures.
4. Adjustable zero point and full scale.
5. Strong anti-interference capability and excellent long-term stability.
Features
1. Aluminum alloy electronic shell with IP65 protection grade.
2. On-site display with simultaneous output of 4 ~ 20mADC and other remote signals.
3. Reverse polarity protection and instant over-current and over-voltage protection measures.
4. Adjustable zero point and full scale.
5. Strong anti-interference capability and excellent long-term stability.
Technical Parameters
Pressure Range(Gauge pressure) | 0~1…200mH2O |
Overload | 1.5x of full scale |
Measuring medium | Liquids |
Output Signal | 4~20mA,4~20mA+Hart, 0-5V,0-10V etc. |
Power Supply | 12~30VDC |
Accuracy | ±0.5%FS(typcial); ±0.25%FS (Optional) |
Long-term Stability | ±0.2%FS/year |
Temperature Coefficient | ±0.03%FS/℃(Reference 25℃) |
Working Temperature | -20~85℃ |
Storage Temperature | -20~120℃ |
Electrical Connection | Directly Cable outlet |
Protection Grade | IP68 |
Technical Parameters
Pressure Range(Gauge pressure) | 0~1…200mH2O |
Overload | 1.5x of full scale |
Measuring medium | Liquids |
Output Signal | 4~20mA,4~20mA+Hart, 0-5V,0-10V etc. |
Power Supply | 12~30VDC |
Accuracy | ±0.5%FS(typcial); ±0.25%FS (Optional) |
Long-term Stability | ±0.2%FS/year |
Temperature Coefficient | ±0.03%FS/℃(Reference 25℃) |
Working Temperature | -20~85℃ |
Storage Temperature | -20~120℃ |
Electrical Connection | Directly Cable outlet |
Protection Grade | IP68 |
