HP3000 Clean Air Digital Differential Pressure Switch with 4-20mA, 0-10V, RS485 &Alarm Output
| Quantity: | |
|---|---|
Overview
The HP3000 offers a variety of measuring ranges to accommodate different applications, including:
a. -500 Pa to 500 Pa
b. -250 Pa to 250 Pa
c. -125 Pa to 125 Pa
d. -60 Pa to 60 Pa
e. Additional ranges can be customized based on specific requirements.
Output Modes:
The HP3000 features multiple output options to enhance its versatility:
Voltage Output: Provides a 0-10V output, suitable for integration with various control systems.
Current Output: Offers a 4-20mA output, ensuring compatibility with standard industrial automation systems.
Switch Alarm Output: Includes 2 normally open channels and 2 normally closed channels for alarm functionalities, allowing for immediate alerts in case of pressure deviations.
Bus Communication: Equipped with RS485 communication utilizing Modbus protocol, enabling seamless integration into digital monitoring systems and facilitating data exchange over long distances.
Highlights:
High Precision: The advanced sensor technology ensures accurate measurements, crucial for process control and monitoring.
Robust Performance: Designed to operate reliably in challenging conditions, the HP3000 is built to last and maintain performance in various industrial environments.
Easy Integration: With multiple output options and communication protocols, the HP3000 can be easily integrated into existing systems, reducing installation time and complexity.
Customizable Features: The ability to tailor measuring ranges and outputs allows users to adapt the transmitter to their specific application needs.
User-Friendly Interface: The LED display enhances usability by providing real-time pressure readings, facilitating quick diagnostics and monitoring.
