HPM580 Four-way anti-explosion Pressure Controller adopts high accurate and high stable silicon pressure core as sensitive element. The built-in signal processing circuit can transform and process the front-end signal of the sensor to output IAO and four-way relay switch value. This product combines the measurement, display, output and control together, with the flexibility, easy operation, safety and reliability features, which can be widely used in hydropower, petroleum, chemical, mechanical and hydraulic and other industries.
HPM580 Four-way anti-explosion Pressure Controller adopts high accurate and high stable silicon pressure core as sensitive element. The built-in signal processing circuit can transform and process the front-end signal of the sensor to output IAO and four-way relay switch value. This product combines the measurement, display, output and control together, with the flexibility, easy operation, safety and reliability features, which can be widely used in hydropower, petroleum, chemical, mechanical and hydraulic and other industries.
Application
Hydropower
Petroleum
Chemical
Machinery
Hydraulic and other industries
Application
Hydropower
Petroleum
Chemical
Machinery
Hydraulic and other industries
Features:
4 bit LED digital tube display
four-way control point relay output
field set control point
4-20mA standard signal output
optional power supply 24VDC or 220VAC
Features:
4 bit LED digital tube display
four-way control point relay output
field set control point
4-20mA standard signal output
optional power supply 24VDC or 220VAC
Technical Parameters
Pressure Range | -100kPa…0~0.01…60MPa | Accuracy | 0.5% |
Overload | 150% | Pressure Type | Gauge /Absolute/Sealed pressure |
Stability | ≤0.1% / year | Power Supply | 24VDC/220VAC |
Display Mode | 0.56" Nixie tube | Display Range | -1999~9999 |
Ambient Temperature | -20℃~70℃ | Relative Humidity | ≤80% |
Installment Thread | Optional | Material | Stainless Steel/BP Explosion-proof |
Technical Parameters
Pressure Range | -100kPa…0~0.01…60MPa | Accuracy | 0.5% |
Overload | 150% | Pressure Type | Gauge /Absolute/Sealed pressure |
Stability | ≤0.1% / year | Power Supply | 24VDC/220VAC |
Display Mode | 0.56" Nixie tube | Display Range | -1999~9999 |
Ambient Temperature | -20℃~70℃ | Relative Humidity | ≤80% |
Installment Thread | Optional | Material | Stainless Steel/BP Explosion-proof |
